Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Product Categories

Henan Strongwin Machinery Equipment Co., Ltd.

Contact Now

Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Name: Belt Type 2TH Poultry Pellet Feed Plant 60KW 15mm Feed
Brand: Strongwin
Price: 1 USD

China Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed wholesale

Brand Name : Strongwin

Model Number : 1.5-2.5t/h feed plant

Certification : CE,ISO

Place of Origin : Henan,China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200 sets per year

Delivery Time : 15-30 working days

Packaging Details : whole production line:by container

Name : Kenya 2 T/H Poultry Feed Manufacturing Process Equipment

Voltage : 380V/50Hz

Power : 60KW

Capacity : 2t/h

Type : Belt type

Feed size : 2-15mm

Service : 24 hours online technical support

Installation : Offer manual book and engineer's guidance

Contact Now

Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Introduction of Poultry Feed Manufacturing Process Equipment

Animal feed pellet process plant is a complete set of machines that are specifically used to make feed pellets.

The machine group generally including the following process: Raw materials receiving and cleaning process, Crushing process, Mixing process, Pellet making process, Pellet cooling process, (pellet crumbling process), Sifting process and Packaging process.

The feed plant widely used to produce pellets for animals,such as chicken, duck, Pigeon, pig, horse, cattle sheep and other poultry and livestock animal. The pellets by our machine have firm and smooth structure and easy digest

Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Technical Parameters of Poultry Feed Manufacturing Process Equipment

No.	Product	Type	Power(KW)
1.Raw materials receiving and crushing and mixing system
101-1	Screw Conveyor	TLSS16	2.2
101-2	Screw Conveyor	TLSS20	3
103	Imitation grinder (including iron remover)	SFPZ56*30	18.5
104	U-shaped ribbon horizontal mixer	LHY1.0	7.5
2.Pelleting system
201	Screw Conveyor	TLSS20	3
202	To be granulated bin (including window)	1.0m³
203	Pellet Machine(include control box)	SZLH250	11*2+2.2+0.75
3.Cooling system
301	Skirt belt conveyor	QBPS400	2.2
302	Buffer bucket	0.2m³
303	Stainless steel air shutter	GFY250	1.1
304	Counter Flow Cooler	SKLN1.0	0.75
305	Air Blower	4-72No4A	5.5
306	Unloader	XL60
307	Wind shut	GFY215	0.75
308	Vibrating screen	SFJZ60*1d	0.25
4.Screening and packaging system
401	Skirt belt conveyor	QBPS400	2.2
402	Buffer bucket	0.5m³
403	Packing scale with sewing bag		2.2
Optional	Simple oil filling system (including pipes and nozzles)	SYVT32	1.5
	Air compression system		3
	Boiler with link system	0.3t/h	3
	Crumbler machine	SSLG15×80	5.5
Price	Welcome contact us for latest price
